Crystal Video CVW Spectra
Skip image gallery
Picture similar to product
Wireless HDMI System up to 350 m
Product number:
000138348
EAN:
0795847448015
Important note
- We only sell to companies, traders, sole traders, freelancers, institutions and authorities.
Product information "Crystal Video CVW Spectra"
The CVW Spectra is a compact and affordable HDMI wireless video transmission system designed for camera setups, streaming, and computer-based video production. It provides stable Full HD video transmission with less than 80 ms latency over distances up to 350 m (line of sight). Supporting 1080p60 via HDMI 1.4, it includes built-in recording and playback functionality directly on the receiver (record button on top).
The receiver’s integrated USB-C UVC output allows direct connection to a laptop for live streaming. Operating in the 5 GHz frequency band, the Spectra features manual channel selection and automatic signal quality monitoring. Both units are lightweight, durable, and can be powered via USB-C, DC, or NP-F batteries.
Main Features:
- Range up to 350 m (line of sight)
- Latency < 80 ms
- HDMI 1.4 input and output
- Full HD 1080p60 transmission (10-bit 4:2:2)
- DFS function for outdoor operation
- Frequency range: 5.1 – 5.9 GHz / 40 MHz bandwidth
- Manual channel selection with LED indication
- Channel scanning with signal strength feedback
- Recording and playback function (on receiver)
- USB-C with UVC output for direct laptop streaming
- Supported video formats: 1080p / 720p
- Audio format: PCM
- Backlit status display for channel, battery, and resolution
- Operating temperature: -10 °C to +45 °C, storage -40 °C to +60 °C
- Power options: USB-C, DC (6–30 V), NP-F battery mount
Included:
- 1× Transmitter (with 2 antennas)
- 1× Receiver (with 2 antennas)
The receiver’s integrated USB-C UVC output allows direct connection to a laptop for live streaming. Operating in the 5 GHz frequency band, the Spectra features manual channel selection and automatic signal quality monitoring. Both units are lightweight, durable, and can be powered via USB-C, DC, or NP-F batteries.
Main Features:
- Range up to 350 m (line of sight)
- Latency < 80 ms
- HDMI 1.4 input and output
- Full HD 1080p60 transmission (10-bit 4:2:2)
- DFS function for outdoor operation
- Frequency range: 5.1 – 5.9 GHz / 40 MHz bandwidth
- Manual channel selection with LED indication
- Channel scanning with signal strength feedback
- Recording and playback function (on receiver)
- USB-C with UVC output for direct laptop streaming
- Supported video formats: 1080p / 720p
- Audio format: PCM
- Backlit status display for channel, battery, and resolution
- Operating temperature: -10 °C to +45 °C, storage -40 °C to +60 °C
- Power options: USB-C, DC (6–30 V), NP-F battery mount
Included:
- 1× Transmitter (with 2 antennas)
- 1× Receiver (with 2 antennas)
